CBN Wheel B6A9/SGT-70x1,5x5x20 for SKI tuning
Regular price:
Regular price:
product unavailable
add to wish list
0
Description
Type: B6A9/SGT-70x1,5x5x20 ( equivalent Snow Glide wheel )
special CBN grinding wheel for grinding and polishing ski and snow board on the special grinder.
CBN wheel B6A9/SGT made with composite resin body for good stiffness, lighter and less vibration work and high working efficiency.
| Product Code | D | W | X | H | T | E | grain size |
| [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | (FEPA) | |
| B6A2/SGT-704520 | 70 | 1,5 | 5 | 20 (H7) |
15 | 5 | please select in check box |
The basic grain size:
CBN grain sizes available on request depend on application - please select the CBN grain size
B15 - for perfect lapping
B25 / B30 / B35 - for finishing and lapping
B46 - for finishing
B64 / B76 - for a little more removal rate
B91 / B107 - for more removal
B126 - for STANDARD grinding
B252 - special CBN grit for fast and maxumim removal and angle correction
Bond:
special resin bond matrix for effective sharpening and long life time.
Application:
CBN grinding wheel for precision grinding, sharpening, finishing and lapping of skis for perfect sharpness.
Replacement grinding stones for SKI grinder. The SKI tuning with DIAMOS grinding stones with different grit provides a perfect finish and long lasting.
Please ask on e-mail:
Certificate:
this product meets the safety standard EN13236.
Phone: +48 32 441 69 90
Information:
The company DIAMOS manufacture and supply very good quality superabrasive wheels, replacement wheels and customized grinding wheels for grinding and sharpening with our brand DIAMOS. The all superabrasive grinding diamond and CBN wheels are engineered and manufactured according to DIAMOS’ technology to be interchangeable with other products and are not OEM parts. The names of the original equipment manufacturers reffered to on this site are all registered trademarks of their respective companies.
